Specifications
1. Recommended Lifting Maximum Force
| Diameter |
Volume |
Lifting Force (↑), Kg |
| (mm) |
(cm³) |
-20 kPa |
-60 kPa |
-90 kPa |
| 30.6 |
16.3 |
1.23 |
3.30 |
4.58 |
2. Weight
| Part Number |
Description |
Weight (g) |
| FF30X-N |
Mark-free suction cup, 30 mm, Nitrile (NBR) |
3.02 |
| FF30X-S |
Mark-free suction cup, 30 mm, Silicone |
2.90 |
| FF30X-WS |
Mark-free suction cup, 30 mm, White silicone |
2.93 |
| FF30X-WS(FDA) |
Mark-free suction cup, 30 mm, White silicone (FDA) |
2.93 |
| FF30X-HS |
Mark-free suction cup, 30 mm, High temp silicone |
3.11 |
| FF30X-CS |
Mark-free suction cup, 30 mm, Conductive silicone |
2.99 |
| FF30X-U |
Mark-free suction cup, 30 mm, Urethane |
3.11 |
| FF30X-A |
Mark-free suction cup, 30 mm, Mark free |
3.30 |
| M5M |
Fitting, M5 x P0.8 male |
7.39 |
3. Material Specifications
| Material |
Hardness Shore (°) |
Color |
Temperature (℃) |
| NBR |
60 |
Black |
-20 ~ 110 |
| Silicone |
55 |
Red |
-70 ~ 200 |
| White Silicone |
55 |
Translucent White |
-70 ~ 200 |
| White Silicone (FDA) |
55 |
Translucent White |
-70 ~ 200 |
| High Temp. Silicone |
50 |
Blue |
-70 ~ 280 |
| Conductive Material |
70 |
Smoky Black |
-45 ~ 90 |
| Urethane |
60 |
Dark Green |
0 ~ 100 |
| Mark Free |
75 |
Black |
-10 ~ 100 |
4. Material Resistance
| Description |
Wear Resistance |
Oil |
Weather/Ozone |
Alcohol |
Acid |
| NBR |
Excellent |
Excellent |
Fair |
Good |
Fair |
| Silicone |
Good |
Poor |
Excellent |
Good |
Poor |
| White Silicone |
Good |
Poor |
Excellent |
Good |
Poor |
| High Temp. Silicone |
Good |
Poor |
Excellent |
Good |
Poor |
| Conductive Silicone |
Good |
Poor |
Excellent |
Good |
Poor |
| Urethane |
Excellent |
Excellent |
Excellent |
Fair |
Poor |
| Mark Free |
Good |
Excellent |
Excellent |
Good |
Excellent |
